Description
-
Equipped with PLC control system with user-friendly interface, ensuring convenient operation, easy maintenance, and stable performance.
-
Noise level: ≤ 65 dB.
-
Machine direction: Left to Right.
-
Infeed conveyor guides are press-fit type for reliable bottle guidance.
-
Standard option: Push buttons / PLC control with colour touch screen panel.
-
Equipment surface material finished in SS 304.
-
Connecting parts comply with GMP-approved engineering plastics.
-
cGMP-compliant, compact, and modular design.
-
All parts coming in contact with bottles or screw caps are made of AISI 304, ensuring good housekeeping.
-
Single motor synchronizes conveyor, star wheels, and platform turret.
-
Electro-pneumatic “No bottle – no cap” system.
-
Fast format changeover from one container size to another due to custom-designed change parts.
-
Equipped with emergency stop button for operator safety.
-
All electrical and bought-out items are CE certified.
-
“No seal in chute – machine stop” safety system.
-
Star wheel and back guide set made of nylon material for long service life.
-
A.C. frequency drive provided for the main drive.
Techanical Specification:-
| Number of Head | Four Head |
| Screw Cap Diameter | Up to 38 mm* |
| Screw Cap Height | Up to 18 mm* |
| Bottle Diameter | Up to 85 mm* |
| Bottle Height | Up to 300 mm* |
| Electrical | 415VAC 3P/220VAC1P Power supply,50Hz/A.C. Drive |
| Power | 2 HP |
| Electrical Load | 1.25 KW |
| Conveyor Height | 8 Feet to be Extend |
| Overall Dimension | 1500(L) X 1000(W) X 2000(H)) |
| Speed | 110 BPM (Depend on Bottle & Cap) |
| Weight | 600 Kg |
